Advantage
High-Precision Cutting
The laser beam, after focusing, has a spot diameter of only 0.1–0.3 mm. Combined with a high-dynamic servo system, it achieves a repeatability of ±0.05 mm and a kerf width of ±0.02 mm. Parts can be directly assembled after a single cutting pass, eliminating the need for secondary deburring.
High-Speed Cutting
The cutting speed for thin sheets is 2–3 times faster than CO₂ lasers of the same power: a 1 kW model can cut 1 mm stainless steel at up to 30 m/min; a 12 kW model can maintain a speed of over 1.8 m/min when cutting 20 mm carbon steel, resulting in an overall efficiency increase of 30–50%.
Multi-Material Compatibility
The standard 1064 nm fiber laser can reliably process carbon steel, stainless steel, aluminum alloys, brass, copper, galvanized sheet metal, titanium alloys, and other materials.
Multi-Process Integration
One machine can perform cutting, micro-joining, scribing, marking, drilling, beveling (0–45°), fly cutting, common-edge cutting, smooth cutting, and high-pressure air cutting, reducing tool change and process switching time.
