Advantage
High Precision: Laser beam focusing spot size of 0.08-0.12 mm, repetitive positioning accuracy of ±0.01 mm, eliminating the need for secondary grinding.
High Speed: Flying cutting of thin tubes, 2-3 times more efficient than sawing/plasma cutting.
Zero Waste: Three-chuck material feeding mode, improving material utilization.
Multi-functional: Cutting, drilling, engraving, and 45° beveling in one process, replacing four processes: sawing, drilling, punching, and milling.
Green and Environmentally Friendly: Non-contact processing with no tool wear; dust and fume purification system filters to ≤0.1 mg/m³, low noise and dust-free.
Intelligent Automation: Automatic feeding, centering, length measurement, and breakpoint continuation cutting; plug-and-play with USB drive, enabling unattended operation during night shifts.
Applicable Materials and Thickness
Metal Materials: Stainless steel, carbon steel, alloy steel, spring steel, copper, aluminum, titanium, nickel and their alloys
Common Thickness: 0.5-25 mm
Cross-sectional Shapes: Round tubes, square tubes, oval tubes, elliptical tubes, angle steel, channel steel, I-beams, H-beams, and other special-shaped tubes
