1200mm 3000mm 6000mm ATC Aluminum Profile Milling And Drilling Machine

A9 aluminum profile drilling and milling machine is applicable to drilling, milling and cutting of industrial aluminum and aluminum profiles of various shapes, covering fields such as mold making, aluminum doors, windows, curtain walls, aluminum furniture and sunroom production. It operates at 380V voltage and has obtained CE, ISO and ROHS certifications. With a 45-day lead time, it can supply 20 sets per month and offers a 2-year warranty. In addition, it supports OEM services, including logo creation and machine customization according to needs, with size customization available.

  • A9

  • YOUHAOCNC

SKU:
Availability:
Quantity:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Auto lubrication

IMG_2271


Constant Cooling Spindle


The HQD 9kw air cooling automatic toolchange spindle operates at 24000 rpm. It offers options like OLISPEEDHITECO and HSD, with a water cooling spindle also available as an alternative.



Servo Motor and Driver


The Leadshine 1500W servo motor is equipped with a Japanese Simpo reducer, and it features a fourth axis harmonic.


IMG_2257
IMG_2256


Contoller System


The Taiwan SYNTEC 60CA control system can automatically realize station conversion.



+90°Rotary Table


It boasts a broad range of processing width and height, capable of handling the machining of various profiles.


IMG_2272
IMG_2265


Lubricatio System


It features automatic lubrication and automatic oil separation functions.



Advantage

  • Suitable for CNC milling and drilling of components in aluminum windows, doors, curtain walls, industrial aluminum, copper, PVC profiles, etc.

  • Incorporates high-precision guide rails, ball screws, gear racks, and imported servo systems, ensuring stable operation with superior positioning and processing accuracy.

  • Equipped with a high-speed electric auto-tool-change spindle, delivering reliable performance.

  • The worktable has dual-end positioning, allowing simultaneous processing of short profiles in two areas to significantly boost efficiency.

  • Features a semi-closed shield and bottom chip receiver, enhancing safety, curbing environmental contamination, and creating a better workspace.

  • Easy to operate with an intelligent CNC system and a clear interface.

  • The rotary worktable can adjust to -90°, 0°, and 90°, enabling three-surface milling and drilling in a single clamping.


Specifications

Bed

thickened steel pipe welding, five-sided milling machining center processing

Working range

3000*200*300mm

Electric spindle

HQD 9kw air cooling  automatic tool change spindle, 24000 rpm

Control system

Taiwan SYNTEC 60CA control system

Drive motor

Leadshine 1500W servo motor with Japanese shimpo reducer, the fourth axis 2000W Leadshine servo motor

Rail

Taiwan HWIN30/25/25

Rack and screw

1.5M crescent and TBI screw

Inverter

Fuling 7.5KW

Table

3 clamps++ 90° flip +Leadshine servo

Lubrication

automatic lubrication and automatic oil separation

Power supply voltage

380V/3Ph/50Hz

Tool changer magazines

8 automatic tool changer magazines

Autonics proximity switches, Sch neider electrical components, AirTAC cylinders, high-flex shielded wires


download YOUHAO CNC catalog.new.pdf
